Re: Polarization in 3D glasses

On 4/16/07 11:03 PM, in article
1176789796.939942.325250@xxxxxxxxxxxxxxxxxxxxxxxxxxx, "avtanski@xxxxxxxxx"
<avtanski@xxxxxxxxx> wrote:

Picture 1: Looking through one of the lenses in a mirror.
As I would expect, one lens looks transparent in the
reflection, the other is black:

http://avtanski.com/images/var/polarization1.jpg

Picture 2: Turning the glasses to look from the wrong side
in - both lens reflections look transparent:

http://avtanski.com/images/var/polarization2.jpg

I have trouble understanding the configuration of your experiment. A diagram
would help.

For example, I do not think you literally mean "in a mirror. The lens is
certainly not in a mirror. There may be an image formed by the mirror.

There are a number of ways in which the stereo effect can be achieved. The
polarization orientations can be at plus and minus 45° rather than
horizontal and vertical. More likely, circular polarization with a quarter
wave film is used.

Bill
-- Fermez le Bush--about two years to go.


.
